Swan's Concrete Products manufactures a range of precast concrete products including septic tanks, D boxes, risers and even frost piers and boat moorings. We enjoy a challenge so contact us with your residential precast concrete project needs and ideas.

Residential Concrete Products:

Click each group to expand and view the full list of products and CAD drawings.

Product Description PDF
RST-0750  750 gallon residential septic tank CAD Drawing
RST-0750-COM-2” 750 gallon residential combo tank with pump and alarm. This is a made to order item only. CAD Drawing
RST-1000 1000 gallon residential septic tank CAD Drawing
RST-1000-COM 1000 gallon residential septic tank with combo insert, NO PUMP CAD Drawing
RST-1000-COM-2” 1000 gallon residential combo tank with pump and alarm. CAD Drawing
RST-1000-H20 1000 gallon residential septic tank, H20 Rated. CAD Drawing
RST-1000-HD 1000 gallon residential heavy duty septic tank, H10 Rated. CAD Drawing
RST-1000-LB 1000 gallon residential low boy septic tank. CAD Drawing
RST-1000-MONO 1000 gallon residential monolithic septic tank. CAD Drawing
RST-1000-B 1000 .gallon residential septic tank bottom only. (These are used as oil containment fields) CAD Drawing
RST-1500 1500 gallon residential septic tank. CAD Drawing
RST-1500HD 1500 gallon residential heavy duty septic tank, H10 Rated CAD Drawing
Product Description PDF
DB-1-5-MINI Distr. Box with cover, 1 in 5 out, 20” x 11.5” x 12”, 65 lbs CAD Drawing
DB-1-5 Distr. Box with cover, 1 in 5 out, 22.5” x 16” x 14”, 200 lbs. CAD Drawing
DB-1-5-BF Distr. Box with cover, 1 in 5 out, with bottom feed CAD Drawing
DB-3-7 Distr. Box with cover, 3 in 7 out, 32” x 16” x 18”, 400 lbs. CAD Drawing
Product Description PDF
HT-1000 1000 gallon holding tank CAD Drawing
HT-750 750 gallon holding tank CAD Drawing
HT-1500 1500 gallon holding tank CAD Drawing
Product Description PDF
STR-29x06 Septic Tank Riser, 29”OD 24” ID x 6” H 14 gal. 130 lbs. CAD Drawing
STR-29x12 Septic Tank Riser, 29”OD 24” ID x 12” H 24 gal. 170 lbs. CAD Drawing
STR-29x16 Septic Tank Riser, 29”OD 24” ID x 16” H 31 gal. 225 lbs. CAD Drawing
STR-29x24 Septic Tank Riser, 29”OD 24” ID x 24” H 47 gal. 340 lbs. CAD Drawing
STR-29x30 Septic Tank Riser, 29”OD 24” ID x 30” H 59 gal. 425 lbs. CAD Drawing
STR-36x06 Septic Tank Riser, 36”OD 06” ID x 6” H 21 gal. 110 lbs. CAD Drawing
STR-36x12 Septic Tank Riser, 36”OD 12” ID x 12” H  41 gal. 220 lbs. CAD Drawing
STR-36x16 Septic Tank Riser, 36”OD 16” ID x 16” H 55 gal. 290 lbs. CAD Drawing
STR-36x24 Septic Tank Riser, 36”OD 24” ID x 24” H 83 gal. 440 lbs. CAD Drawing
Product Description PDF
STRC-29 Riser Cover, 29” DIA 135 lbs. CAD Drawing
STRC-29-HD Riser Cover, 29” DIA x 6” MADE TO ORDER  270 lbs. CAD Drawing
STRC-29-IC Riser Cover, 29” DIA with 16.5” x 12.5” Inspection Cover 135 lbs. CAD Drawing
STRC-36 Riser Cover, 36” DIA 175 lbs. CAD Drawing
STRC-36-A Riser Cover, 36” DIA with 20” DIA access pot, 175 lbs CAD Drawing
STRC-36-HD Riser Cover, 36” DIA x 6” 350 lbs. CAD Drawing
Product Description PDF
PTS-100 Pump Tank Station, 100 gallon with ½ HP pump and alarm CAD Drawing
PTS-300 Pump Tank Station, 300 gallon with ½ HP pump and alarm CAD Drawing
PT-100-WC Pump Tank & Cover, 100 gallon (no pump) CAD Drawing
PT-300-WC Pump Tank & Cover, 300 gallon (no pump) CAD Drawing
Product Description PDF
PTR-41X13 Pump Tank Riser, 41”OD 36”ID 340 lbs. CAD Drawing
PTR-41X24 Pump Tank Riser, 41”OD 36”ID 630 lbs CAD Drawing
PTR-41X30  Pump Tank Riser, 41”OD 36”ID 785 lbs. CAD Drawing
PTR-54X13 Pump Tank Riser, 54”OD 36”ID 495 lbs. CAD Drawing
PTR-54X24 Pump Tank Riser, 54”OD 36”ID 990 lbs. CAD Drawing
PTR-54X48 Pump Tank Riser, 54”OD 36”ID 1,975 lbs. CAD Drawing
Product Description PDF
LC-13-L-H20 Concrete Leaching Chamber, 4’x8’x13”, H20 Rated, END FEED CAD Drawing
LC-13-L-HD Concrete Leaching Chamber, 4’x8’x13”, H10 Rated, END FEED CAD Drawing
LC-13-S-H20 Concrete Leaching Chamber, 4’x8’x13”, H20 Rated, SIDE FEED CAD Drawing
LC-13-S-HD Concrete Leaching Chamber, 4’x8’x13”, H10 Rated, SIDE FEED CAD Drawing
LC-ENVI Enviro-Septic Pipe 10’L x 12”OD CAD Drawing
LC-ENVI-CUP;  Enviro-Septic Coupling CAD Drawing
LC-ENVI-END Enviro-Septic End Cap CAD Drawing
LC-ENVI-OFF-D Enviro-Septic Offset Double Adapter CAD Drawing
LC-ENVI-OFFSET Enviro-Septic Offset Adapter CAD Drawing
LC-EQUAL;  Enviro-Septic Equalizers CAD Drawing
LC-ENVIROFIN New! Enviro-Septic EnviroFin Meets or Exceeds NSF/ANSI Standard 40 CAD Drawing
Product Description PDF
GEN-3X4 Generator Pad, 4’x3’x4” 600 lbs. CAD Drawing
GEN-3X5 Generator Pad, 5’x3’x4” 740 lbs. CAD Drawing
GEN-4X8 Generator Pad, 8’x4’x6” MADE TO ORDER 2,370 lbs. CAD Drawing
OTP-275 275 gallon Oil Tank Pad, 60”x27”x3.5”, 485 lbs. CAD Drawing
OTP-330 330 gallon Oil Tank Pad, 72”x 29” x 4”, 715  CAD Drawing
OTPH Horizontal 275 Oil Tank Pad, 60” x 44” x 4”, 900 lbs. CAD Drawing
PTP-0500 500 gallon Propane Tank Pad, 8’x3’x4, 1,185 CAD Drawing
PTP-1000 1000 gallon Propane Tank Pad, 12’x4’x6”, 3,555 CAD Drawing
PTPU-1000 1000 gallon Underground Propane Tank Pad, 16’x5’x7 5/8” CAD Drawing
PTPU-500 500 gallon Underground Propane Tank Pad, 10’x40”x7 5/8”, CAD Drawing
PTP-24 Round Propane Tank Pad, 24” DIA., 80 lbs. 24/pallet CAD Drawing
PTP-28 Round Propane Tank Pad, 28” DIA., 106 lbs. 12/pallet CAD Drawing
PTP-30 Round Propane Tank Pad, 30” DIA., 120 lbs. 12/pallet CAD Drawing
PTP-4x8x20 Propane Tank Pads, 4”x8”x20”, 65 lbs. 40/pallet CAD Drawing
PTP-4x8x30 Propane Tank Pads, 4”x8”x30”, 85 lbs. 40/pallet CAD Drawing
TP-SP Single Phase Transformer Pad, 2630 CAD Drawing
TPC-SP Single Phase Transformer Pad Cover CAD Drawing
Product Description PDF
FP-4 4’ tapered Frost Pier, 6” x 6” top, 12” x 12” base, 375 lbs. CAD Drawing
FP-5 5’ tapered Frost Pier, 6” x 6” top, 14” x 14” base, 410 lbs. CAD Drawing
FP-6 6’ tapered Frost Pier, 6” x 6” top, 16” x 16” base, 530 lbs. CAD Drawing
FP-WB 4’ tapered Frost Pier with Base, 6” x 6” top, 23” x 23” base, 475 lbs. CAD Drawing
Product Description PDF
FPR-18X4 Reinforced Round Footing Pad, 18” DIA. X 4”, 80 lbs. CAD Drawing
FPR-18X6 Reinforced Round Footing Pad, 18” DIA. X 6”, 120 lbs. CAD Drawing
FPR-24X4 Reinforced Round Footing Pad, 24” DIA. X 4”, 150 lbs. CAD Drawing
FPR-24X6 Reinforced Round Footing Pad, 24” DIA. X 6”, 240 lb CAD Drawing
Product Description PDF
SB-F Splash Block Fluted End CAD Drawing
SB-R Splash Block Round End CAD Drawing
Product Description PDF
RST-COV-A Septic Tank Cover, Access, 20” DIA CAD Drawing
RST-COV-I-L Septic Tank Cover, Large Inspection CAD Drawing
RST-COV-I-S Septic Tank Cover, Small Inspection CAD Drawing
RST-CTC Combo Tank Insert Cover CAD Drawing
RST-CTI Combo Tank Insert, ~600 lbs. CAD Drawing
RST-CTR Combo Tank Riser, 34” x 34” x 12” CAD Drawing
Product Description PDF
SP-CMP Heavy Duty 4’ x 6’ Splice Box CAD Drawing
Product Description PDF
BM-85 18” DIA Boat Mooring with galvanized hook CAD Drawing
BM-130 18” DIA Boat Mooring with galvanized hook CAD Drawing
BM-150 24” DIA Boat Mooring with galvanized hook CAD Drawing
BM-250 24” DIA Boat Mooring with galvanized hook CAD Drawing
